ABSTRACT: India Automotive Industry Standards Commission AISC released draft AIS-038 Rev.2 / D1 for electric vehicle power systems and AIS-156 / D1 for electric two-wheelers power systems on September 30, 2019 for public comment and it is expired on October 29, 2019. Recently, ATIC had completed Indian AIS-038 electric vehicle traction battery test witness for several top manufacturers domestically. These manufacturers were the firsts to test since this standard was released, and would obtain the certification report soon.
The previous regulation AIS-048 included test methods for power batteries used in M, N, and L category vehicles. I had been revised several times since firstly issued in 2009. However, due to the rapid development of electric vehicles and traction battery technology, some of the test items of the predecessor regulations could not fully adapt to the development of new technologies. Thus approved by the Ministry of Surface Transport (MoST), the Automotive Industry Standards Committee (AISC) initiated the regulatory revision process, and published the draft regulations of AIS-038 and AIS-156. The new regulation AIS-038 subjected to traction batteries used in passenger cars and commercial vehicles (M and N vehicles) and AIS156 subjected to traction battery used in two-wheeled vehicles (type L vehicles).
BRIEF ANALYSIS OF NEW AND OLD REGULATIONS
Compared with the previous regulation AIS-048, the new regulations AIS038 / AlS156 were changed greatly in terms of regulatory framework, technical requirements, and test methods. The previous regulation AIS-048 could test at the cell, module, and battery pack levels, and no environmental test item was included. The new regulations AIS-038 / AIS-156 got closer to EU standards, and were added with environmental tests and thermal propagation. Test objects became mainly the battery system, subsystem and even the entire vehicle. Besides, nail penetration was removed which was the most concerning test item before.
BRIEF ANALYSIS OF AIS038 REV.2/D1
The regulatory framework of AIS038 refered to UNECE R100 Rev. 3 draft, test methods were completely equivalent to UN GTR 20 Phase 1, but technical requirements were unique. Nail penetration test at cell / module level in the AIS-048 was removed. Shock test (SOC 100%) was replaced by mechanical shock (SOC 95%). To be noted that the technical requirements and test methods of AIS-038 was more strict than the current UNECE R100 Rev.2. Such in vibration test, thermal shock, mechanical shock, and mechanical integrity, the initial condition in ECE R100 Rev.2 only should be high than 50% SOC, but in AIS-038, the SOC should be not less than 95%. Compare with China GB 38031-2020 which also refered framework of GTR 20, the AIS-038 was less strict in test methods and less test items, but more strict in initial conditions and after test requirements.
ATIC ONE-STOP CMVR CERTIFICATION SERVICEs
ATIC, as the designated technical service organization of ARAI of the Indian Automobile Research Institute, provides one-stop Indian CMVR certification for domestic manufacturers. The mandatory vehicle certification scope of the CMVR regulations includes: electric vehicle BOV, two-wheel and three-wheel vehicles, four-wheel passenger vehicles and trucks (M1, N1), light and heavy commercial vehicles (M2, M3, N2, N3), diesel/gasoline generator sets, etc. And safety-related components are also required to be certified in the CMVR regulations, including: power batteries, on-board positioning system with emergency call button, safety glass, brake hose, horn, tire, seat belts, hubs, lighting and signaling devices, retroreflectors, triangular warning signs, reflective strips, replaceable LED light sources, child seats Brake pads, helmets, seats and headrests, automotive electronics, and wiper blades, etc.
SERVICES PROVIDED BY ATIC
1. Testing and trial-testing of IS and AIS standards
2. India CMVR (whole vehicles and components), BIS (consumer products, automotive components and electronic information products), WPC/TEC (wireless communication products) certification services
3. Preparation and translation of a complete set of application materials
4. Factory audit guidance, accompanied by translation throughout
5. Direct co-operation with authorities and certification bodies without communication barriers
6. Local representative available
ATIC is a young technical service company from China, established in 2015. ATIC is comitted to integrate domestic and international regulations, testing and certification resources with a global perspective in the context of globalization, and establish a new, specialized regulation research, testing and certification platform. With innovative Digital Reporting System (DRS), Customer Service Platform (CSP) and self-developed Global Vehicle Regulation Database (GVRD), ATIC's compliance service covers more than 54 countries/regions globally, testing and certification service covers more than 30 countries/regions worldwide. ATIC serve more than 3,300 manufactures each year.
