Lighting and Light Signaling Devices Global Homologation Solution
Establish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets

Global Homologation Matrix – Automotive Lighting
Motor vehicle lighting and signaling devices are one of the active safety components of motor vehicles, and their performance is critical to vehicle safety. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements for automotive lighting and signaling devices.


 China EU North America Japan AustraliaKorea Germany
Vietnam India UAE BrazilMexico Argentina
Certification
CCCEMARK DOT AMECA Type Approval ADRKMVSS / KC KMARK VR CMVR ESMA INMETRONOM CHAS
Authority
Certification and Accreditation Administration of the People's Republic of China
Ministry of Transportation of member states of 1958 Agreement
Department of Transportation
Automotive Manufacturers Equipment Compliance Agency
Japan Ministry of Land, Infrastructure, Transport and Tourism
Department of Infrastructure, Transport, Cities and Regional Department
Korea Ministry of Land, Infrastructure and Transport
Germany Ministry of Transportation
Vietnam Ministry of Transportation
The Ministry of Road Transport, Highways
Emirates Authority for Standardization and Metrology
National Institute of Metrology, Standardization and Industrial Quality
Mexican Ministry of Economy
Argentine Ministry of Industry
Testing Location
China
China / Europe
China / US
China / US
China / Japan
China
China / Korea
Germany
Vietnam
China / India
China
China / Brazil
China / Mexico
China / Argentina
Conformity of Production
Self-declaration
Initial Assessment + CoP
None
None
None
None
None
Initial Assessment + CoP
Initial Audit + Surveillance Audit
Initial Assessment + CoP
Based on QMS certificates
Initial Audit + Surveillance Audit
Initial Audit + Surveillance Audit
Initial Audit + Surveillance Audit
Regulation/
Standard
GB 11554, GB 5920, GB 5920, GB 15235, GB 17509, GB 18408, GB 18409, GB 18099, GB 23255, GB 17510, GB 11564, GB 25990, GB/T 30511, GB 4599, GB 21259, GB 25991, GBT 30036, GB 5948, GB 19152, GB 4660, GB 23254
ECE R3, 4, 6, 7, 19, 23, 27, 37, 38, 50, 69, 70, 77, 87, 98, 99, 104, 112, 113, 123, 128
FMVSS 108
FMVSS 125
SAE
FMVSS 108
FMVSS 125
SAE
Device Type Approval Procedure
Safety Rules
Article 32, 33, 62, 33-2, 33-3, 34, 34-2, 34-3, 37, 37-2, 37-3, 37-4, 39, 39-2, 40, 41, 41-2, 41-3, 41-4, 41-5, 62-2, 62-3, 62-4, 63-3, 35, 35-2, 38, 63, 38-2, 38-3, 43-3, 43-4
ADR 1, 6, 13, 19, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 60, 67, 74, 75, 76, 77, 78, 86
KMVSS Article 38, 38-2, 38-3, 38-4, 38-5, 39, 40, 40-2, 40-3, 41, 42, 43, 44, 47, 48, 58, 75, 75-2, 75-3, 76, 77, 77-2, 78, 79, 79-2, 81, 82, 112-4, 112-5, 112-8, 112-9, 112-12, 112-13
§ 22a StVZO TA 14b
§ 22a StVZO TA 14c
§ 22a StVZO TA 23
§ 22a StVZO No. 18
QCVN 35-2010 / BGTVT
AIS-008, AIS-009, AIS-010, AIS-012, AIS-030, AIS-034, AIS-062, AIS-083, AIS-127, AIS-128, AIS-022, AIS-057, AIS-088, AIS-089, AIS-090
ECE R104, ECE R48
Ordinance no. 301 of 07/21/2011
NMX-D-233-1984
UN Regulations IRAM AITA 10031
Main test items

General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation

General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation
Photometry
Color
Wear Test
Chemical Resistance
Corrosion Resistance
Dust Test
Temperature and Heat Test
Humidity Test
Vibration Test
Aiming Test
Material Test
Water-Proof Test
Durability Test
Structural and Functional Inspection
Photometry
Color
Wear Test
Chemical Resistance
Corrosion Resistance
Dust Test
Temperature and Heat Test
Humidity Test
Vibration Test
Aiming Test
Material Test
Water-Proof Test
Durability Test
Structural and Functional Inspection
General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation
General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation

General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation
General Provisions
Photometry
Color
Low Voltage Indication Signal
Low Battery Test
Immersion Test
Structural Requirements
Photometry
Color
Stability
General Provisions
Shape and Dimension
Photometry
Color
Stability
Environmental Test
Hardness
Adhesion Performance
Impact Test
Bending Resistance
Water Resistance
Washing Resistance
General Provisions
Shape and Dimension
Color
CIL
Light Intensity
Environmental Test
General Provisions
Light Intensity / CIL
Color
Shape and Dimension
Environmental Test
Dimensions
Lamp Holder
Electrical Parameters
Photometry
Life Test
Vibration and Shock
Anti-Torque
Bulb Strength
General Provisions
Illuminance / Light Intensity / Brightness
Color
Plastic Lens Test
LED Module Test
Shape and Dimension
Environmental Test
Optical Parameters
Location and Size
Ultraviolet Radiation
Marks
ATIC | A Testing Inspection Certification Company
www.atic-cn.com
Get a Quotation Now

Log in to ATICTM Digital Customer Platform to request quotations, browse 16000+ regulations and
SoPs cover more than 54 countries, submit information documents and manage your certification projects.

Global Homologation Solution

ATIC CCC Certification Service

China Compulsory Certification (CCC) system is based on the  Product Quality Law, Import and Export Commodity Inspection Law and Standardization Law. The compulsory certification products are related to human health, animal and plant safety, environmental protection, public safety, and national security. Automotive lighting and signaling devices and reflective markings shall be subject to compulsory certification in accordance with the implementation rules of the CNCA: CNCA-C11-07 External Lighting and Optical Signaling Devices for Motor Vehicles and CNCA-C11-13 Reflective Markings.

In addition, according to the Chinese National Certification and Accreditation Administration Committee (CNCA) Notice No. 44 of 2019, automotive lighting, signaling devices and reflective markings are  subject to self-declaration scheme. Manufactures or its representative shall submit compliance information and self-declaration in a timely, accurate and comprehensive manner to CNCA.

Standards:
GB 11554, GB 5920, GB 5920, GB 15235, GB 17509, GB 18408, GB 18409, GB 18099, GB 23255, GB 17510, GB 11564, GB 25990, GB/T 30511, GB 4599, GB 21259, GB 25991, GBT 30036, GB 5948, GB 19152, GB 4660, GB 23254

Test Items:
General provisions, illuminance / light intensity / luminosity, color, plastic lens test, LED module test, shape and size, environmental test, photoelectric parameters, position and size, ultraviolet radiation, etc.

Procedure:
Documentation and sample preparation, testing, rectification (if any), submit compliance information and sign self-declaration

Please click here for more certification:
ATIC EU Homologation

Focusing on road safety, environmental protection and public health, people may mention three sets of famous regulations when they talk about European Type Approval System: German StVZO, EU Regulations and UN Regulations. StVZO standards apply to Germany, EU Regulations apply to EU/EEA/EFTA member states, while UN Regulations may accepted by EU and more than 50 UNECE member states.

Regulations:
ECE R3, ECE R4, ECE R6, ECE R7, ECE R19, ECE R23, ECE R27, ECE R37, ECE R38, ECE R50, ECE R69, ECE R70, ECE R77, ECE R87, ECE R98, ECE R99, ECE R104, ECE R112, ECE R113, ECE R123, ECE R128, ECE R148, ECE R149, ECE R150

Test Items:
General specification, illuminance / light intensity / luminosity, color, plastic lens test, LED module test, shape and size, environmental test, photoelectric parameters, position and size, ultraviolet radiation, etc.

Procedure:
Information document, initial assessment, witness test, rectification (if any), apply for approval, conformity of production

Please Click here for more EU homologation:
dcb5232a203a2a1fb91eeebb45aebf69

The United States Department of Transportation, abbreviated DOT, is headquartered in Washington. As the functional department of the US government, the US Department of Transportation develops and improves transportation and transportation-related regulations to meet environmental and national defense needs. The Department of Transportation is also a basic department of the federal government, responsible for formulation and management to protect and improve the safety, appropriateness and effectiveness of transportation system. According to the regulations of the US Department of Transportation, where vehicles and critical components are exported to the US market, they must pass DOT certification and mark the corresponding DOT mark on the product. The product has passed the DOT certification and is marked with the corresponding mark, indicating that the product meets the requirements of the Federal Motor Vehicle Safety Standard (FMVSS) and has passed the corresponding test or manufacturer's statement.

Regulations:
FMVSS 108, FMVSS 125, SAE

Test Items:
Photometry, Color, Wear Test, Chemical Resistance, Corrosion Resistance, Dust Test, Temperature and Heat Test, Humidity Test, Vibration Test, Aiming Test, Material Test, Water-Proof Test, Durability Test, Structural and Functional Inspection

Procedure:
Testing, DOT marking, registration to NHTSA

Please click here for more North America certifications:
北美ameca

The North American Parts Compliance Program (ECP) promoted by AMECA (The Automotive Manufacturers Equipment Compliance Agency, Inc.) is a centralized, voluntary, one-stop process. It is a procedure for informing the government, industry and the general public that motor vehicle safety components have been tested in AMECA authorized laboratories and that they meet relevant standards. Products with an AMECA certificate will be more easily procured by North American buyers and users. AMECA provides product testing related services by authorizing third-party laboratories. Only test reports issued by AEMCA authorized laboratories will be approved by AMECA.

Standards:
FMVSS108, SAE J593, SAE J1432, SAE J592, SAE J852, SAE J910, SAE J823, SAE J2595, SAE J602, SAE J587, SAE J222, SAE J576, SAE J594/SAE J2041, SAE J2042, SAE J586/SAE J2261/SAE J1957, SAE J585/SAE J2040, SAE J1690/SAE J823, SAE J588/SAE, J1373/SAE, J1432/SAE J2261, SAE J914/SAE J2039, SAE J589B, FMVSS125, SAE J1383, SAE J581, SAE J582, SAE J583, SAE J1432, SAE J595, SAE J845, SAE J1318, SAE J2498, SAE J1133, FMVSS131, SAE J887, SAE J584, SAE J131, SAE J1306, USCAR 33

Test Items:
Photometry, Color, Wear Test, Chemical Resistance, Corrosion Resistance, Dust Test, Temperature and Heat Test, Humidity Test, Vibration Test, Aiming Test, Material Test, Water-Proof Test, Durability Test, Structural and Functional Inspection

Procedure:
Application, testing, certificate issuance, annual audit (if applicable)

Please click here for more North America certifications:
ATIC Japan Vehicle Type Approval Service

Japanese automotive homologation system is ranked among the world's three major automotive homologation systems together with European and the United States. The core motor vehicle regulations are the Road Vehicle Law, the Motor Vehicle Type Designation Rules, the Security Standards for Road Transport Vehicles, and the Air Pollution Prevention Law.

Motor vehicle lighting and signaling devices need to meet requirements specified in the Security Standards for Road Transport Vehicles and the Equipment Type Designation Rules. The technical requirements for most systems and components are consistent with UNECE regulations. For automotive lighting and signaling devices in case UNECE regulation is mentioned as equivalent regulation in Equipment Type Designation Rules, there is no need to apply for the type designation to Japanese authority again when UNECE type approval certificates are available. During the whole vehicle type designation, UNECE certified parts shall bear the approval mark and submit information documents and type approval certificates to the Ministry of Land, Infrastructure, Transport and Tourism for review. For motor vehicle lighting and signal devices that UNECE regulation is not mentioned as equivalent regulation in Equipment Type Designation Rules, relevant tests shall be carried out according to the technical requirements in Security Standards for Road Transport Vehicles and the Type Designation Test Procedures, the evaluation process is consistent with the whole vehicle evaluation process.


Standard:
Security Standards for Road Transport VehiclesEquipment Type Designation Rules

Test Items:
General Specification, Illuminance / Light Intensity / Brightness
Color, Plastic Lens Test, LED Module Test, Shape and Dimension, Environmental Test, Optical Parameters, Location and Size, Ultraviolet Radiation

Please click here for more Japan certification:
ADR certification

Before a new vehicle can be registered for the first time in Australia, it must meet the requirements of the Motor Vehicle Standards Act 1989 (the Act). The Act applies to all new vehicles - whether road motor vehicles or road trailers. Under the Act, new vehicles are required to be fitted with an identification plate (formerly known as a compliance plate). The identification plate provides a clear indication to the state or territory registering authority - and to the owner and the general public - that the vehicle is ready for use in transport on public roads in Australia.

In Australia, the entire process from application to obtaining an Identification Plate is called Certification. The entire certification process is managed by Australian Department of Infrastructure, Transport, Regional Development and Communications and operated through Vehicle Safety Standards Branch (VSS).

The scope of vehicle certification includes: Motor Vehicles, Trailers, Tractors, Bicycles, Used Imported Cars, Special Vehicles, etc. Component certification includes: Automotive Lamps, Rearview Mirrors, Seat Belts, Brake Hoses, Glass, Tires, Retro-reflectors, Filament Bulbs, Couplings, Seats, etc.


Standards:
ADR 1, ADR6, ADR13, ADR19, ADR45, ADR46, ADR47, ADR48, ADR49, ADR50, ADR51, ADR52, ADR53, ADR54, ADR55, ADR60, ADR67, ADR74, ADR75, ADR76, ADR77, ADR78, ADR86

Test Items:
General Provisions, Illuminance / Light Intensity / Brightness
Color, Plastic Lens Test, LED Module Test, Shape and Dimension, Environmental Test, Optical Parameters, Location and Size, Ultraviolet Radiation

Procedure:
Submit application, test, rectification (if any), registration

Please click here for more Australia certification:
ATIC Korea Vehicle Type Approval

A person who intends to manufacture, assemble or import a motor vehicle (including the incomplete motor vehicle and the motor vehicle manufactured by phase) shall self-authenticate that the model of the relevant motor vehicle meets the safety standards (Korea Motor Vehicle Safety Standard - KMVSS) for motor vehicles (in cases of an incomplete motor vehicle or a motor vehicle manufactured by phase, referring to the safety standards for motor vehicles to be applied as at the time when a manufacture, etc. concerned is finished), as determined by Ordinance of the Ministry of Land, Infrastructure and Transport (MOLIT).

For certain automotive parts entering the aftermarket, KC (Korea Certification) scheme is applied which was regulated by the Ministry of Industry. From 2018, Ministry of Land, Infrastructure and Transport (MOLIT) has taken over the regulating and supervising responsibilities of KC certification for automotive components.

Standards:
KMVSS Article 38, 38-2, 38-3, 38-4, 38-5, 39, 40, 40-2, 40-3, 41, 42, 43, 44, 47, 48, 58, 75, 75-2, 75-3, 76, 77, 77-2, 78, 79, 79-2, 81, 82, 112-4, 112-5, 112-8, 112-9, 112-12, 112-13

Test Items:
General Provisions, Illuminance / Light Intensity / Brightness
Color, Plastic Lens Test, LED Module Test, Shape and Dimension
Environmental Test, Optical Parameters, Location and Size, Ultraviolet Radiation

Procedure:
Submit application, testing, registration

Please click here for more Korea certification:
电动平衡车StVZO认证

The Federal Motor Transport Authority (Kraftfahrt-Bundesamt - KBA) grants type-approvals for complete and incomplete vehicles and for vehicle components (parts, systems, separate technical units) in accordance with national and international statutory regulations. The KBA also grants type-approvals in accordance with some other regulations that are not directly related to road traffic (e.g. exhaust gases emitted by mobile machinery).

ATIC offers type-approval services according to the german national vehicle safety standard (StVZO) (Allgemeine Betriebserlaubnisse - ABE and Allgemeine Bauartgenehmigungen - ABG) for products such as wheels, bicycle lamps and electric scooters to make your products more competitive in the European market.

Standards:
§ 22a StVZO TA 14b, § 22a StVZO TA 14c, § 22a StVZO TA 23 , § 22a StVZO No. 18

Test Items:
General Provisions, Photometry, Color, Low Voltage Indication Signal, Low Battery Test, Immersion Test

Procedure:
Prepare information document, initial assessment, testing, approval

Please click here for more Germany certification:
ATIC Vietnam Vehicle Type Approval Serivce
821e52f4085d629cdf134c79c788e01b

CMVR is the abbreviation of Central Motor Vehicles Rules. Its standard committee is called CMVR-TSC (CMVR-Technical Standing Committee) and belongs to the Indian Ship, Road Traffic and Highway Administration. Since 1991, the CMVR regulations stipulate that motor vehicles and their systems and components must be approved according to the CMVR regulations before entering the Indian market. The tests includes Safety, Emissions and the type approval process includes Factory Audit, Type Testing and Conformity of Production (CoP).

Standard:
AIS-008, AIS-009, AIS-010, AIS-012, AIS-030, AIS-034, AIS-062, AIS-083, AIS-127, AIS-128, AIS-022, AIS-057, AIS-088, AIS-089, AIS-090

Test Items:
General Provisions, Shape and Dimension, Photometry, Color
Stability, Environmental Test, Hardness, Adhesion Performance
Impact Test, Bending Resistance, Water Resistance, Washing Resistance


Procedure:
Application, factory audit, sample test, approval, surveillance audit

Please click here for more India certification:
ATIC UAE ESMA Certification

The Cabinet Resolution No (12) of 2018 Automotive Spare Parts was published in 2018 by Prime Minister, United Arab Emirates which stipulates that 14 categories of auto parts are prohibited to import or place the product in the market subject to the provisions of this decision unless it is registered in accordance with the UAE conformity assessment scheme (ECAS) and has obtained a certificate of conformity in accordance with the provisions of this resolution. Including: Brake Systems, Brake Pads, Engine Radiators, Safety Belts, Rear View Mirrors, Batteries, Oil Filters for Internal Combustion Engines, Air Filters, Laminated Safety Glass, Rims, Door Locks and Door Hinges, Retro-reflective Markings and Signaling Devices, Alarm Systems for Buses and Commercial Vehicles, Relays and Flashers.

Standard:
ECE R104, ECE R48

Test Items:
General Provisions, Shape and Dimension, Color, CIL, Light Intensity, Environmental Test

Procedure:
Application, testing, review, issuing certificate
89d11b55d1c5e11f879c90af5925f4dc-400x229

The Mexican government has established relevant standards for various products in accordance with the Mexican Federal Metrology and Standardization Law. The main government agency for the certification management of various products, including automotive products, is the Ministry of Economy of Mexico. In addition to standard and regulation revisions, it is also responsible for the designation and accreditation of product certification bodies and laboratories.
The Norma Oficial Mexicana - NOM standards are mandatory, at present, Mexico has established a relatively complete NOM certification system for limited product categories, including electronic, electrical, communication products, lighting devices, medical equipment, tires, toys, and battery-driven products.

Standard:
NMX-D-233-1984

Test Items:
General Provisions, Light Intensity / CIL, Color, Shape and Dimension, Environmental Test

Procedure:
Submit application, factory audit (if needed), sample tests (if needed), certificate issuance
零部件

INMETRO (National Institute of Metrology, Standardization and Industrial Quality) is a government department directly under the Ministry of Development, Industry and Foreign Trade of Brazil. With the enactment of new ordinances and implementation laws, more and more products are included into INMETRO mandatory certification scheme.

Standard:
Ordinance no. 301 of 07/21/2011

Test Items:
Dimensions, Lamp Holder, Electrical Parameters, Photometry, Life Test, Vibration and Shock, Anti-Torque, Bulb Strength

Procedure:
Certification application, importer audit, document review, factory audit, sampling and tests, certificate issuance, INMETRO registration, maintenance audit

Please click here for more Brazilian certification:
Argentina Component Type Approval

Argentine Ministry of Industry’s Regulation No. 91 of 2001 and Regulation No. 66 of 2008 established the mandatory certification system (Certificate of Homologation of Auto Safety Part - Certificado de Homologación de Autoparte de Seguridad - C.H.A.S.) for Argentine automotive aftermarket parts and safety units, which is applicable for both imported or local produced products. Related aftermarket parts shall be certified and registered with the Argentine Ministry of Industry before being allowed to be sold in the Argentine market.

Standard:
UN Regulations IRAM AITA 10031

Test Items:
General Provisions, Illuminance / Light Intensity / Brightness, Color, Plastic Lens Test, LED Module Test, Shape and Dimension, Environmental Test, Optical Parameters, Location and Size, Ultraviolet Radiation

Procedure:
Application, factory audit, testing, certificate issuance, surveillance

Please click here for more Argentina certification:

Multinational Homologation Solutions
ATIC provides more than 28 categories' system, separate technical unit, component multinational compliance and homologation solutions

Europe, the United States, Japan, Korea, China and India have a comprehensive electric vehicle homologation system. Emerging markets such as the Middle East, Indonesia, and Thailand are gradually developing electric vehicle standards. Our service includes multinational regulations identification, comparison, training and Q&A.

CNG/LPG Components
Many countries established regulations and homologation procedures for clean energy applications. ATIC team has accumulated many years homologation experience in this area. We are now providing comprehensive services including multinational regulations identification, regulation comparison, training, Q&A, testing and homologation.

Brake system components such as brake lining, brake pads and shoes, brake discs are critical safety components. Most countries established compulsory certification scheme for both original and replacement parts. Our market access solution including regulation consulting, training, testing and certification covering all the relevant countries/regions world wide.

Tires are required for mandatory certification in many countries. Besides safety testing, many countries are introducing labelling requirements with regard to the display of information on the fuel efficiency, wet grip and external rolling noise of tires. ATIC provides multinational consulting and homologation services for tires, especially for emerging markets.

In-vehicle communication system is more and more important in internet of vehicle systems. Both automotive and telecom regulations need to be considered. Relying on our professional team and regulation database ATIC provides in-vehicle communication system homologation, training and consulting services covering more than 17 countries.

CNG/LPG Components
Many countries established regulations and homologation procedures for clean energy applications. ATIC team has accumulated many years homologation experience in this area. We are now providing comprehensive services including multinational regulations identification, regulation comparison, training, Q&A, testing and homologation.
