Automotive Traction Battery Global Homologation SolutionEstablish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets
Automotive Traction Battery Global Homologation Solution
Establish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets
Global Homologation Matrix - Automotive Traction BatteryAutomotive traction batteries are one of the most important safety components of motor vehicles, and their performance is critical to vehicle safety. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements for automotive traction batteries.
Global Homologation Matrix - Automotive Traction Battery
Automotive traction batteries are one of the most important safety components of motor vehicles, and their performance is critical to vehicle safety. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements for automotive traction batteries.
| China | UNECE | America | South Korea | India | UN 38.3 | |
Certification |  |
 |
 |
 |
 |
 |
| CCC | EMARK | SAE | KMVSS | CMVR | UN 38.3 | |
|
Authority
| CNCA |
Ministry of Transportation of contracting parties of 1958 agreement
|
Ministry of Transport |
Ministry of Land and Transport |
Ministry of Road Transport and Highways |
UN |
|
Testing Location
| China |
China / EU |
China / US |
China / South Korea |
India |
China |
DUT | Pack | Pack | Cell, Module, Pack | Pack | Module, Pack | Cell, Module |
|
Conformity of Production
| Initial Audit + Surveillance Audit |
Initial Assessment + COP
|
N/A |
N/A |
Initial Assessment + COP
|
N/A |
|
Regulation /
Standard | GB18384-2020 GB38031-2020 GB38032-2020 (effective from 01.01.2021) GB/T 31467.1-2015 GB/T 31467.2-2015 GB/T 31467.3-2015 GB/T 31484-2015 GB/T 31485-2015 GB/T 31486-2015 (about to be abolished) |
ECE R100-Part II |
SAE J1797 SAE J1798 SAE J2464 SAE J2380 SAE J2929 SAND2005-3123 UL 2580 |
KMVSS 18.3 KMVSS TP 48 KSR 1204 |
AIS 038 Rev 2 (effective soon) AIS 048 (about to be abolished） |
UN 38.3 |
|
Main Test Items *The specific test items may different for different product categories or specifications. | Vibration Test Mechanical Shock
Crash Test Crush Test Dewing Immersion External Fire Thermal Propagation Temperature Shock Salt Spray Altitude Simulation Over-temperature Over Current External Short Circuit Test Overcharge Over Discharge |
Vibration Test Mechanical Shock
Mechanical Integrity Thermal Shock and Cycling Test Fire Resistance Over- temperature Protection External Short Circuit Protection Overcharge Over-discharge protection |
Shock Tests Drop Test
Penetration Test Roll-over Test Crush Test High Temperature Hazard Test Thermal Stability Test Cycling without Thermal Management Thermal Shock Cycling Passive Propagation Resistance Test Immersion Test Short Circuit Test Overcharge Test Over discharge (Forced Discharge) Test Over- temperature Protection Separator Shutdown Integrity Test |
Drop Test Immersion Test
Fire Resistance Over-temperature protection Short Circuit Test Overcharge Test Over-discharge Test Vibration Test Thermal Shock Test Overcurrent Test Mechanical Test |
Vibration Test Mechanical Shock
Mechanical Integrity Thermal Shock and Cycling Test Fire Resistance Over- temperature Protection Thermal Propagation Test External Short Circuit Protection Overcharge Over-discharge Protection Over Current Test |
T1: Altitude Simulation
T2: Thermal test T3: Vibration test T4: Shock test T5: External short circuit test T6: Impact/crush test T7: Over-charge T8: Over-discharge |
 ATIC | A Testing Inspection Certification Company www.atic-cn.com | ||||||
Get a Quotation Now
Submit quotation request or login to ATICTM Digital Customer Platform to view quotations, browse 16,000+ regulations and
SoPs cover more than 54 countries, submit information documents and manage your certification projects.
Global Homologation Solution
China Compulsory Certification (also known as CCC certification) is the compulsory product certification in China. According to the requirements of CNCA (Certification and Accreditation Administration of the People’s Republic of China), all products listed in the compulsory product certification catalog which does not obtain a certificate or apply certification marks in accordance with regulations, shall not be imported, shipped from the factory, or enter into Chinese market.
On May 12, 2020, GB 18384-2020 Electric Vehicles Safety Requirements, GB 38032-2020 Electric Buses Safety Requirement and GB 38031-2020 Electric Vehicles Traction Battery Safety Requirements, three mandatory national standards are officially released and will be implemented from January 1, 2021. Theses three mandatory standards are the first mandatory national standards in the field of electric vehicles in China, and are also the basic requirements for the approval of new energy vehicle products.
Standard:
GB/T 31467.1-2015, GB/T 31467.2-2015, GB/T 31467.3-2015, GB/T 31484-2015, GB/T 31485-2015, GB/T 31486-2015
Test Items:
Vibration Test, Mechanical Shock, Crash Test, Crush Test, Dewing, Immersion, External fire, Thermal propagation, Temperature Shock, Salt spray, Altitude simulation, Over-temperature, Over current, External short circuit test, Overcharge, Over discharge
Procedure:
Documentation and sample preparation, testing, report issuance
Please click here for more certification:
Focusing on road safety, environmental protection and public health, people may mention three sets of famous regulations when they talk about European Type Approval System: German StVZO, EU Regulations and UN Regulations. StVZO standards apply to Germany, EU Regulations apply to EU/EEA/EFTA member states, while UN Regulations may accepted by EU and more than 50 UNECE member states.
Regulation:
ECE R100-PartII
Test Items:
Test Items:
Vibration test, Mechanical Shock, Mechanical integrity, Thermal shock and cycling test, Fire resistance, Over- temperature protection, External short circuit protection, Overcharge, Over-discharge protection
Procedure:
Submit application, initial factory audit (if any), witness test, rectification (if any), certificate application and issuance
Please Click here for more EU Certification:
The United States Department of Transportation, abbreviated DOT, is headquartered in Washington. As the functional department of the US government, the US Department of Transportation develops and improves transportation and transportation-related regulations to meet environmental and national defense needs. The Department of Transportation is also a basic department of the federal government, responsible for formulation and management to protect and improve the safety, appropriateness and effectiveness of transportation system. According to the regulations of the US Department of Transportation, where vehicles and critical components are exported to the US market, they must pass DOT certification and mark the corresponding DOT mark on the product. The product has passed the DOT certification and is marked with the corresponding mark, indicating that the product meets the requirements of the Federal Motor Vehicle Safety Standard (FMVSS) and has passed the corresponding test or manufacturer's statement. Traction battery as component is not covered by FMVSS, but for US market whole vehicle manufactures may request traction battery fulfills SAE, SAND, UL, etc. standards.
Regulation:
SAE J1797, SAE J1798, SAE J2464, SAE J2380, SAE J2929, SAND2005-3123, UL 2580
Test Items:
Shock Tests, Drop Test, Penetration Test, Roll-over Test, Crush Test, High Temperature Hazard Test, Thermal Stability Test, Cycling without Thermal Management, Thermal Shock Cycling, Passive Propagation Resistance Test, Immersion Test, Short Circuit Test, Overcharge Test, Over discharge (Forced Discharge) Test, Over- temperature protection, Separator Shutdown Integrity Test
Please click here for more North America certification:
Compulsory acts and regulations stipulate that any motor vehicle entering the South Korean market must be certified by the Ministry of Land, Infrastructure and Transport (MOLIT), Ministry of Environmental Protection (MoE) and Ministry of Industry (MoI) through certification scheme of safety, environmental protection and fuel consumption. For electric vehicles, the Appraisal Tests, which is regulated by MoE is required. The MoE of the Republic of Korea subsidizes the models that have passed the test. The amount of subsidies varies according to the policies.
A person who intends to manufacture, assemble or import a motor vehicle (including the incomplete motor vehicle and the motor vehicle manufactured by phase) shall self-authenticate that the model of the relevant motor vehicle meets the safety standards (Korea Motor Vehicle Safety Standard - KMVSS) for motor vehicles (in cases of an incomplete motor vehicle or a motor vehicle manufactured by phase, referring to the safety standards for motor vehicles to be applied as at the time when a manufacture, etc. concerned is finished), as determined by Ordinance of the Ministry of Land, Infrastructure and Transport.
According to KMVSS traction battery shall be tested in accordance with KMVSS Article 18-3 and the test procedure KMVSS TP 48. At the same time, for certain category vehicles their Lithium-ion traction batteries must obtain KS R1204 test report during MoE certification and Subsidy application.
Standard:
KMVSS 18.3, KMVSS TP 48
KMVSS 18.3, KMVSS TP 48
Test Items:
Drop test, Immersion test, Fire resistance, Over-temperature protection, Short circuit test, Overcharge test, Over-discharge test, Vibration test, Thermal shock test, Overcurrent test, Mechanical Test
Please click here for more Korea certifications:
CMVR is the abbreviation of Central Motor Vehicles Rules. Its standard committee is called CMVR-TSC (CMVR-Technical Standing Committee) and belongs to the Indian Ship, Road Traffic and Highway Administration. Since 1991, the CMVR regulations stipulate that motor vehicles and their systems and components must be approved according to the CMVR regulations before entering the Indian market. The tests includes Safety, Emissions and the type approval process includes Factory Audit, Type Testing and Conformity of Production (CoP).
As the designated technical service agency of ARAI, ATIC conducts regular technical exchange with ARAI and provides manufacturers with one-stop Indian CMVR vehicle and component type approval service.
Standard:
AIS 038 Rev 2 (coming soon)
AIS 048 (to be cancelled)
Test Items:
Vibration test, Mechanical Shock, Mechanical integrity, Thermal shock and cycling test, Fire resistance, Over- temperature protection, Thermal Propagation Test, External short circuit protection, Overcharge, Over-discharge protection, Over current test
Procedure:
Application, sample test, test report issuance
Please click here for more India certification:
Chapter 38.3 of Recommendations on the Transport of Dangerous Goods - Manual of Tests and Criteria (referred to as UN38.3) provides detailed regulations for the transport of hazardous materials in lithium metal and lithium ion batteries. The UN38.3 test simulates transportation conditions, such as pressure, temperature, extrusion, impact, etc., and is respectively called the T1 to T8 test.
As of January 1, 2019, the 6th revised edition of Recommendations on the Transport of Dangerous Goods - Manual of Tests and Criteria has become effective (Rev. 6 and -/ Amend.1). Cells, battery cells, single-cell batteries, cells as components (cells that are not shipped separately), and battery packs have different test requirements and different sample requirements.
Standard:
UN 38.3
UN 38.3
Test Items:
T1: Altitude Simulation, T2: Thermal test, T3: Vibration test, T4: Shock test, T5: External short circuit test, T6: Impact test, T7: Over-charge, T8: Over-discharge
T1: Altitude Simulation, T2: Thermal test, T3: Vibration test, T4: Shock test, T5: External short circuit test, T6: Impact test, T7: Over-charge, T8: Over-discharge
Procedure:
Prepare information document, perform testing, issue reports
Prepare information document, perform testing, issue reports
