BRIEF ANALYSIS OF CMS EU TYPE APPROVAL OF CAMERA-MONITOR SYSTEM

BRIEF ANALYSIS OF CMS EU TYPE APPROVAL OF CAMERA-MONITOR SYSTEM

RELEASE DATE:2021-04-21 11:47
ABSTRACT: CMS (Camera-Monitor System, hereinafter referred to as CMS), replaces the inner rearview mirror and two outer rearview mirrors with cameras and monitors. "Camera" means a device that renders an image of the outside world and then converts this image into a signal (e.g. video signal); "Monitor" means a device that converts a signal into images that are rendered into the visual spectrum. According to the UN R46 regulations, whether CMS products are installed with the Vehicle or CMS products in the aftermarket, they must pass the UN Only with Regulation No.46 certification can it enter Europe or be sold in more than 50 UNECE countries.



ADVANTAGES OF CMS
1. Reduce wind resistance and wind noise, reduce fuel consumption
2. A wider field of vision, enhanced visibility, and higher security
3. Support vision-based analysis
4. Vehicle Aesthetics

CMS GENERAL REQUIREMENTS (PARTIAL)
1. If adjustment by the user is needed, the device for indirect vision shall be adjustable without the use of tools.
2. If a device for indirect vision can only render the total prescribed field of vision by scanning the field of vision, the total process of scanning, rendering and reset to its initial position together shall not take more than 200 milliseconds at room temperature of 22 °C ± 5 °C.
3. The effectiveness of the CMS of Classes I to IV shall not be adversely affected by magnetic or electrical fields. This shall be demonstrated by compliance with the technical requirements and transitional provisions of Regulation No. 10, 04 series of amendments or any later series of amendements.

TYPE APPROVL PROCESS
1. Submit application
2. Initial assessment
3. Information document and testing sample preparation
4. Testing and reporting
5. Type approval certificate issuing

CMS  HOMOLOGATION REQUIREMENTS

No.
Test Items
Suitable
1
General requirements
Whole Vehicle or component
2
Luminance adjustment
Component
3
Operating readiness (System availability)
Whole Vehicle
4
Monitor isotropy
Component
5
Luminance and contrast rendering
6
Grey scale rendering
7
Colour rendering
8
Artefacts Smear
9
Artefacts  Blooming and lens flare
10
Artefacts   Point light sources
11
Sharpness and depth of field
12
Geometric distortion
13
Flicker
14
Frame rate
15
Image formation time
16
System latency
17
Glare due to high luminance of the monitor
18
Impact test
Component
19
Intended use, activation and deactivation
Whole Vehicle
20
Default view
Component
21
Luminance and contrast adjustment
Whole Vehicle
22
Overlay requirements within the minimum required field of vision
Whole Vehicle or Component
23
Operating readiness (System availability)
Whole Vehicle
24
Magnification and resolution
Component
25
Magnification aspect ratio
Component
26
Monitor inside the vehicle
Whole Vehicle
27
Obstruction of the driver's direct view
Whole Vehicle
28
Decreasing accommodation
Whole Vehicle
Remarks: Non-parts items are not applicable for EU type approval of CMS Component.

ATIC SERVICE ABOUT EU/UN HOMOLOGATION
ATIC experts are working under designated technical services in Europe to conduct Initial Assessment, Witness Testing and CoP assessment as authorized inspectors with authorities including e/E4 Netherland, e/E5 Sweden, e/E24 Ireland, e/E49 Cyprus, e/E32 Latvia and e/E36 Lithuania.
Also, ATIC is qualified ATS-Point who is designated by Sammarinese Approval Authority, through which type approval certificates of Vehicles, components, technical units and Vehicle systems according to UN Regulations are issued with the code E57.
In China, our witness laboratories cover North China, Central China and South China. No matter where your products are produced, we can provide the nearest witness test site. If your factory laboratory meets the requirements of ISO17025, We can also perform witness tests in your factory and apply type approval certificate.
ATIC leading digital customer platform and digital reporting system make it easy for you to submit information files online, and technical reports can be generated online, minimizing file and report preparation time and improving quality, leaving valuable time to you and yours client.
