Motor Vehicle Audible Warning Devices Global Homologation SolutionEstablish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets
Motor Vehicle Audible Warning Devices Global Homologation Solution
Establish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets
Global Homologation Matrix – Audible Warning DevicesAudible warning device (also referred to as horns) which is intentionally operated by a driver, emit an acoustic signal which is intended to give audible warning of the presence of a vehicle in a dangerous road traffic situation. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements for the audible warning device in the aftermarket.
Global Homologation Matrix – Audible Warning Devices
Audible warning device (also referred to as horns) which is intentionally operated by a driver, emit an acoustic signal which is intended to give audible warning of the presence of a vehicle in a dangerous road traffic situation. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements for the audible warning device in the aftermarket.
| China | UNECE | India | Brazil | Argentina | Australia | EAEU | |
Certification |  |
 |
 |
 |  |
 |
 |
| CQC | EMARK | CMVR | INMETRO | CHAS | ADR | EAC | |
|
Authority
| China Quality Certification Centre |
Ministry of Transportation of contracting parties of 1958 agreement |
The Ministry of Road Transport and Highways |
National Institute of Metrology, Standardization and Industrial Quality | Argentina National Directorate of Industry |
Australia Department of Transportation |
Eurasian Economic Commission |
|
Testing Location | China |
China / EU |
India |
China / Brazil | China / Argentina |
China / Australia |
Russia / Kazakhstan |
|
Conformity of Production
| Initial Inspection + Surveillance Inspection |
Initial inspection + conformity of production |
Initial inspection + conformity of production |
Initial Inspection + Surveillance Inspection | Initial inspection + conformity of production |
Random Inspection |
Initial Inspection+ Surveillance Inspection |
|
Regulation /
Standard | GB15742 |
UN Regulation No. 28 |
IS 1884-993 |
Ordinance No. 301 | IRAM-AITA/UN Regulation No. 28 |
ADR 94 |
Item No.62 of Appendix No.10 of TP TC 018/2011 |
|
Main Test Items *The specific test items may different for different product categories or specifications. | General specifications Sound pressure level
Endurance test |
General specifications Sound pressure level Endurance test |
Visual examination and dimensional check High voltage test
Current draw test Operation voltage range test Sound pressure level test Insulation resistance (humid) test Endurance test Vibration test Corrosion resistance test Dust test Damp heat (cycling) test Water spray proof test Water sealing test Temperature stability test |
Tests for determining consumption Tests for determining frequency
Test on electrical insulation Operating temperature range Temperature cycle tests Thermal exposure test Tightness test Continual operation test Corrosion tests to check electrical behavior Corrosion tests to check external finish Vibration tests Durability | General specifications Sound pressure level Endurance test |
General specifications Sound pressure level Endurance test |
General specifications Sound pressure level Endurance test |
 ATIC | A Testing Inspection Certification Company www.atic-cn.com | |||||||
Get a Quotation Now
Submit quotation request or login to ATICTM Digital Customer Platform to view quotations, browse 16,000+ regulations and
SoPs cover more than 54 countries, submit information documents and manage your certification projects.
Global Homologation Solution
CCC certification (China Compulsory Certification), is a product conformity assessment system implemented by the Chinese government in order to protect consumers' personal safety and national security, strengthen product quality management, and comply with laws and regulations. The CCC certification is a mandatory certification required by the People's Republic of China for the import, export, manufacture, sale, and use of various products. Only certified products can be considered to meet mandatory requirements in terms of safety, electromagnetic compatibility (EMC), and environmental protection.
The CQC mark certification is one of the voluntary product certification services carried out by the China Quality Certification Center CQC. By adding the CQC mark, it indicates that the product meets the relevant quality, safety, performance, electromagnetic compatibility and other certification requirements. The certification scope covers mechanical equipment, power Equipment, electrical appliances, electronic products, textiles, building materials and more than 500 products. The CQC mark certification focuses on safety, electromagnetic compatibility, performance, and hazardous substance limits, which directly reflect product quality and affect consumers' personal and property safety. It aims to safeguard consumer interests, promote product quality, and enhance the international competitiveness of domestic companies.
Motor vehicle horns were once in the CCC mandatory certification scope, and were certified in accordance with China National Certification and Accreditation Administration CNCA-C11-05 Motor Vehicle Horn Compulsory Product Certification Implementation Rules. According to the 2018 Announcement No. 11 issued by the State Administration of Market Regulation of China in June 2018, the horn of motor vehicles has been removed from the scope of compulsory certification products, and no compulsory certification is currently being carried out.
Although motor vehicle horns no longer require mandatory CCC certification, manufacturers can consider CQC mark certification (voluntary certification) as appropriate. China Quality Certification Center has included the scope of CQC mark certification. According to CQC16-491283-2018 Motor Vehicle Horn Implementation Rules Certification of electric horns and air horns for M, N, L motor vehicles.
Motor vehicle horns were once in the CCC mandatory certification scope, and were certified in accordance with China National Certification and Accreditation Administration CNCA-C11-05 Motor Vehicle Horn Compulsory Product Certification Implementation Rules. According to the 2018 Announcement No. 11 issued by the State Administration of Market Regulation of China in June 2018, the horn of motor vehicles has been removed from the scope of compulsory certification products, and no compulsory certification is currently being carried out.
Although motor vehicle horns no longer require mandatory CCC certification, manufacturers can consider CQC mark certification (voluntary certification) as appropriate. China Quality Certification Center has included the scope of CQC mark certification. According to CQC16-491283-2018 Motor Vehicle Horn Implementation Rules Certification of electric horns and air horns for M, N, L motor vehicles.
Standard:
GB 15742-2019
Test Items:
General specifications, Sound pressure level, Endurance test
Please click here for more certification:
Focus on road safety, environmental protection and public health. The so-called EU certification system is completed by the German StVZO standard, the EU Directive/Regulation and the UNECE Regulation. The StVZO standard applies to Germany, the EU directives/regulations apply to more than 30 European Free Trade Association countries, and UNECE is accepted by the EU and more than 50 countries in the UN framework. It‘s commonly known as German ABE certification, e-mark certification and E-mark certification.
Regulation:
UN Regulation No. 28: Uniform provisions concerning the approval of audible warning devices and of motor vehicles with regard to their audible warning signals
Test Items:
Test Items:
General specifications, Sound pressure level, Endurance test
Procedure:
Submit application, initial factory audit (if any), witness test, rectification (if any), certificate application and issuance
Please click here for more EU certification
CMVR is the abbreviation of Central Motor Vehicles Rules. Its standard committee is called CMVR-TSC (CMVR-Technical Standing Committee) and belongs to the Indian Ship, Road Traffic and Highway Administration. Since 1991, the CMVR regulations stipulate that motor vehicles and their parts and components must be approved for type approval according to the CMVR regulations before entering the Indian market. The test items include safety and emissions. The certification procedure includes factory audit, type certification and consistency of production.
As the designated technical service agency of ARAI, ATIC conducts regular technical exchanges with ARAI and provides manufacturers with one-stop Indian CMVR vehicle and component certification.
Standard:
IS 1884-1993 Automotive vehicles-Electric horns-Specification
Test Items:
Visual examination and dimensional check, High voltage test, Current draw test, Operation voltage range test, Sound pressure level test, Insulation resistance (humid) test, Endurance test, Vibration test, Corrosion resistance test, Dust test, Damp heat (cycling) test, Water spray proof test, Water sealing test, Temperature stability test
Procedure:
Submit applications, audits, samples sent to Indian laboratories, testing, rectification (if any), certificate application, certificate issuance
Please click here for more India certification:
The National Institute of Metrology, Standardization and Industrial Quality, abbreviated as INMETRO, is a government department directly under the Ministry of Development, Industry and Foreign Trade of Brazil. INMETRO's product range includes home appliances, medical devices, automotive parts, LED light sources, pressure vessels, etc. With the enactment of more new regulations and implementation rules, more and more products are included in the INMETRO mandatory certification.
Standard:
Ordinance No. 301 - Horn or similar equipmentused in automotive road vehicle
Test Items:
Tests for determining consumption, Tests for determining frequency, Test on electrical insulation, Operating temperature range, Temperature cycle tests, Thermal exposure test, Tightness test, Continual operation test, Corrosion tests to check electrical behavior, Corrosion tests to check external finish, Vibration tests, Durability
Procedure:
Certification application, legal agent audit, document review, factory audit, sampling test, certificate issuance, INMETRO registration, supervision audit
Please click here for more Brazilian certification:
The CHAS certification in Argentina is for the certification of auto parts. According to the regulations of the Argentine Ministry of Industry and the regulations No. 66, the relevant auto parts that are produced or imported locally need to be registered and certified by the Argentine Ministry of Industry. Allow sales in the Argentine market.
At present, the Brazilian CHAS compulsory certification parts include wheels, triangle warning signs, helmets, safety belts, brake pads, brake fluid, safety glass, fire extinguishers, headrests, seats and fixing points, coupling devices, rotary locks, vacuum pumps, batteries, Rearview mirrors, steering rods and ball heads, shock absorbers, steering boxes, horns, wipers and their components, automotive lamps, ballasts, safety vests, door lock door hinges, anti-theft and alarm devices, child restraint systems, safety Airbag system, brake components, axles, bumpers, etc.
At present, the Brazilian CHAS compulsory certification parts include wheels, triangle warning signs, helmets, safety belts, brake pads, brake fluid, safety glass, fire extinguishers, headrests, seats and fixing points, coupling devices, rotary locks, vacuum pumps, batteries, Rearview mirrors, steering rods and ball heads, shock absorbers, steering boxes, horns, wipers and their components, automotive lamps, ballasts, safety vests, door lock door hinges, anti-theft and alarm devices, child restraint systems, safety Airbag system, brake components, axles, bumpers, etc.
Regulation:
IRAM-AITA/UN Regulation No. 28: Horns of motor vehicles
Test Items:
General specifications, Sound pressure level, Endurance test
Please click here for more Argentina certification:
The importation of vehicles to Australia is prohibited except in very specific circumstances. Most vehicles are imported by large manufacturers that invest substantially in research and development to ensure that every new vehicle meets minimum safety standards that maintain the safest possible environment for all road users and our community. Manufacturers wanting to import vehicles to Australia for supply must first obtain a Vehicle Type Approval.
Approved companies known as Registered Automotive Workshops (RAWs) may import a limited range of used vehicles on behalf of individuals. Individuals can also apply to import vehicles to Australia. A Vehicle Import Approval is required to import a vehicle. The vehicle will not be released from customs control by the Australian Border Force (ABF) unless it has a Vehicle Import Approval.
Before a new vehicle can be registered for the first time in Australia, it must meet the requirements of the Motor Vehicle Standards Act 1989 (the Act). The Act applies to all new vehicles - whether road motor vehicles or road trailers. Under the Act, new vehicles are required to be fitted with an identification plate (formerly known as a compliance plate). The identification plate provides a clear indication to the state or territory registering authority - and to the owner and the general public - that the vehicle is ready for use in transport on public roads in Australia.
The Road Vehicle Standards Act 2018 (RVSA) and associated Road Vehicle Standards Acts relating to consequential and transitional provisions and charges passed Parliament in late 2018. The Road Vehicle Standards Rules 2019, which cover the operational aspects of the RVSA, were made in February 2019. The RVSA will replace the existing Motor Vehicle Standards Act 1989 (MVSA) and deliver an updated and modernized system to regulate the first provision of road vehicles to the Australian market.
In Australia, the entire process from application to obtaining an Identification Plate is called Certification. The entire certification process is managed by Australian Department of Infrastructure, Transport, Regional Development and Communications.
The scope of vehicle certification includes: Motor Vehicles, Trailers, Tractors, Bicycles, Used Imported Cars, Special Vehicles, etc.
Component certification includes: Automotive Lamps, Rearview Mirrors, Seat Belts, Brake Hoses, Glass, Tires, Retro-reflectors, Filament Bulbs, Couplings, Seats, etc.
Approved companies known as Registered Automotive Workshops (RAWs) may import a limited range of used vehicles on behalf of individuals. Individuals can also apply to import vehicles to Australia. A Vehicle Import Approval is required to import a vehicle. The vehicle will not be released from customs control by the Australian Border Force (ABF) unless it has a Vehicle Import Approval.
Before a new vehicle can be registered for the first time in Australia, it must meet the requirements of the Motor Vehicle Standards Act 1989 (the Act). The Act applies to all new vehicles - whether road motor vehicles or road trailers. Under the Act, new vehicles are required to be fitted with an identification plate (formerly known as a compliance plate). The identification plate provides a clear indication to the state or territory registering authority - and to the owner and the general public - that the vehicle is ready for use in transport on public roads in Australia.
The Road Vehicle Standards Act 2018 (RVSA) and associated Road Vehicle Standards Acts relating to consequential and transitional provisions and charges passed Parliament in late 2018. The Road Vehicle Standards Rules 2019, which cover the operational aspects of the RVSA, were made in February 2019. The RVSA will replace the existing Motor Vehicle Standards Act 1989 (MVSA) and deliver an updated and modernized system to regulate the first provision of road vehicles to the Australian market.
In Australia, the entire process from application to obtaining an Identification Plate is called Certification. The entire certification process is managed by Australian Department of Infrastructure, Transport, Regional Development and Communications.
The scope of vehicle certification includes: Motor Vehicles, Trailers, Tractors, Bicycles, Used Imported Cars, Special Vehicles, etc.
Component certification includes: Automotive Lamps, Rearview Mirrors, Seat Belts, Brake Hoses, Glass, Tires, Retro-reflectors, Filament Bulbs, Couplings, Seats, etc.
Standard:
ADR 94 -Audible Warning
Test Items:
General specifications, Sound pressure level, Endurance test
Procedure:
Prepare application documents and submit, Testing, Rectification (if any), Registration completed
Please click here for more Australia certifications:
The Eurasian Economic Union (EAEU), also known as the Eurasian Union (EEU), was formerly the Customs Union (abbreviated as CU) of Russia, Belarus and Kazakhstan. Armenia and Kyrgyzstan subsequently joined the union, and the Eurasian Economic Union was formally established in 2015.
Eurasian Conformity (EAC) is a product certification system formulated and implemented by the Eurasian Union. At present, the Eurasian Union is expected to issue 66 product technical regulations, and 48 regulations have been enforced. The product scope covers a wide range of food, electrical appliances, children products, transportation, chemicals, light industrial products and other fields. All products listed in the unified list of EAC certification, without obtaining a certificate or applying the certification mark in accordance with regulations, shall not be imported, sold, or used in business service places.
The Eurasian Union member states recognize the certification bodies and laboratories, and the EAC certificate is valid among the member states. According to Article 54 of the EAEU treaty on May 29, member states shall mutually recognize the certification of conformity assessment bodies (including certification bodies and testing laboratories) in the national certification system of member states. EAC certificate replaces previous Russian GOST-R certificate, Kazakhstan GOST-K certificate and Belarus BelST certificate.
ATIC established long term partnership with certification bodies and testing labs in Russia and Belarus, based on ATIC regulation, standard and conformity assessment database providing efficient one-stop EAC certification services in China.
Eurasian Conformity (EAC) is a product certification system formulated and implemented by the Eurasian Union. At present, the Eurasian Union is expected to issue 66 product technical regulations, and 48 regulations have been enforced. The product scope covers a wide range of food, electrical appliances, children products, transportation, chemicals, light industrial products and other fields. All products listed in the unified list of EAC certification, without obtaining a certificate or applying the certification mark in accordance with regulations, shall not be imported, sold, or used in business service places.
The Eurasian Union member states recognize the certification bodies and laboratories, and the EAC certificate is valid among the member states. According to Article 54 of the EAEU treaty on May 29, member states shall mutually recognize the certification of conformity assessment bodies (including certification bodies and testing laboratories) in the national certification system of member states. EAC certificate replaces previous Russian GOST-R certificate, Kazakhstan GOST-K certificate and Belarus BelST certificate.
ATIC established long term partnership with certification bodies and testing labs in Russia and Belarus, based on ATIC regulation, standard and conformity assessment database providing efficient one-stop EAC certification services in China.
Standard:
Item No.62 of Appendix No.10 of TP TC 018/2011- On the safety of wheeled vehicles-Audible warning devices and of motor vehicles
Test Items:
General specifications, Sound pressure level, Endurance test
Please click here for more Australia certifications:
