Motor Vehicle Brake Components Global Homologation Solution
Establish a global certification program at the product development and design stage, proactively, orderly, and low-risk access to multiple target markets

Global Homologation Matrix - Brake Components
Motor Vehicle Brake Components are one of the most important safety components of motor vehicles, and their performance is critical to vehicle safety. In order to ensure vehicle safety and road traffic safety, many countries around the world have mandatory certification requirements.


  ChinaChinaEU USA Japan AustraliaSouth Korea Philippines
Vietnam India UAE BrazilEAEU Argentina
Certification
CCCCQCEMARK DOT AMECA JIS ADRKC BPS VR CMVR ESMA INMETROEAC CHAS
Authority
Certification and Accreditation Administration of the People's Republic of China
China Quality Certification Centre
Ministry of Transportation of member states of 1958 Agreement
Department of Transportation
Automotive Manufacturers Equipment Compliance Agency
Japan Ministry of Economy, Trade and Industry
Department of Infrastructure, Transport, Cities and Regional Department
Korea Ministry of Land, Infrastructure and Transport
Bureau of Philippine Standards
Vietnam Ministry of Transportation
Ministry of Road Transport and Highways
Emirates Authority for Standardization and Metrology
National Institute of Metrology, Standardization and Industrial Quality
Eurasian Economic Union
Argentine Ministry of Industry
Testing Location
China
China
China / Europe
China / US
China / US
Japan
China
Korea
China / Philippines
Vietnam
India
China
China
China / Russia
China / Argentina
Conformity of Production
Initial Audit + Surveillance Audit
Initial Assessment + CoP
Initial Assessment + CoP
None
None
Initial Assessment + CoP
Possible Factory Audit
None
Initial Audit + Surveillance Audit
Initial Audit + Surveillance Audit
Initial Assessment + CoP
None
Initial Audit + Surveillance Audit
Initial Assessment + CoP
Initial Assessment + CoP
Regulation /
Standard
GB 5763
GB 16897
ECE R90
ECE R13
ECE R13H
ECE R78
FMVSS 106
FMVSS 116
SAE J 1288-2005
SAE J 1401-2003
SAE J 1402-2006
SAE J 1403-2005
SAE J 1406-2007
SAE J 1873-2003
SAE J 75-2006
SAE J 291-1980
SAE J 1703-2008
SAE J 1704-2008
SAE J 1705-2007
SAE J 1706-1995
SAE J 1707-2002
FMVSS 106
FMVSS 116
VESC V-3
SAE J 1288-2005
SAE J 1401-2003
SAE J 1402-2006
SAE J 1403-2005
SAE J 1406-2007
SAE J 1873-2003
SAE J 75-2006
SAE J 291-1980
SAE J 1703-2008
SAE J 1704-2008
SAE J 1705-2007
SAE J 1706-1995
SAE J 1707-2002
JISD4413
JISD4414-1
JISD4414-2
JISD4415
JISD4416
JISD4417
JISD4418
JISD4419
JISD4420
JISD4421
JISD4422
JISK2233
JISD2601
ADR 7
ADR 42
KMVSS Article 112-2
KMVSS Article 112 -10
National Technical Standards Notice No. 2017-032
PNS 239/MVSS 116:1988

22TCN 296-02
TCVN 11496-2016
TCVN 11497-2016
TCVN 11498-2016
TCVN 11499-2016
TCVN 11500-2016
TCVN 11501-2016
TCVN 11502-2016
TCVN 11503-2016
TCVN 11496-2016
TCVN 6822-2001
TCVN 6823-2001
TCVN 7237-2003
TCVN 7236-2003
TCVN 7235-2003
AIS-061
IS 7079-2008
UAE.S/GSO ECE 90 UAE.S GSO ECE 13-1 UAE.S GSO ECE 13-2 UAE.S GSO ECE 13-3 UAE.S GSO ECE 13-4 UAE.S GSO ECE 13-5 UAE.S GSO ECE 13-6 UAE.S GSO ECE 13H
Ordinance no. 55
Ordinance no. 78
TR TS 030/2012
IRAM AITA 6-C2
IRAM AITA, 6H1, 6H2, 6H3, 6H4, 6H5, 6H10
Components
Brake lining
Brake hose (hydraulic / pneumatic / vacuum)
Brake lining, Brake drum and brake disc
Brake fluids, Brake hose (hydraulic / pneumatic / vacuum)
Brake lining, Brake fluids, Brake hose (hydraulic / pneumatic / vacuum)
Brake lining, Brake fluids, Brake hose (hydraulic)
Brake hose (hydraulic / pneumatic / vacuum)
Brake lining, Brake Fluids, Brake hose (hydraulic / pneumatic / vacuum)
Brake fluids
Motorcycle brake hose
Brake lining, Brake hose (hydraulic)
Brake lining, Brake drum and brake disc
Brake lining, Brake fluids
Brake fluids
Brake lining, Brake fluids
Main test items
*The specific test items may different for different product categories or specifications.

Brake lining
Asbestos detection
Harmful elements detection
Friction performance test
Shear strength test
Brake hose
Expansion test
Burst strength test
Anti-jitter test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
1) Brake lining
Brake testing
Cold performance equivalence test
Speed sensitivity test
Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient
2) Brake drum and brake disc
Geometric requirements
Performance tests according to Regulations No. 13/13-H
Comparison test with dynamic frictional properties of the original part
High load and thermal fatigue test

1)  Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
2) brake hose-hydraulic, pneumatic, vacuum
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
etc.

1) Brake Linings
Baseline Run
First Run
Wear run
Second Run
Baseline Rerun
2) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
3) brake hose-hydraulic, pneumatic, vacuum
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
etc.
1) Brake Linings
Compressive strain test
Anti-rust test
Shear strength test
Thermal expansion test
Hardness Testing
Shear test
2) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
3) Hydraulic brake hose
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
1) brake hose-hydraulic, pneumatic, vacuum
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
High temperature resistance test
Oil resistance test
Length change test
Flex strength and air pressure test.
Corrosion resistance and burst strength test
Water Absorption and tensile strength test
Zinc chloride resistance test
Vacuum test
Bend test
Swell and adhesion test
Deformation test

1) Brake Linings
Compressibility test
Shear strength test
Hardness Testing
2) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
3) brake hose-hydraulic, pneumatic, vacuum
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
etc.
1) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
1) Motorcycle brake hose
Tolerance for length
Requirement of fitting
Installation of cap and cove
Threaded joints requirement
Length of patchwork and lead holding material
Surface defects
Conductor surface requirements
Installation of protective covers
Slip resistance
Control performance
Durability
1) Brake lining
Brake testing
Cold performance equivalence test
Speed sensitivity test
Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient
2) Hydraulic brake hose
Expansion test
Burst strength test
Whip resistance test
Tensile strength test
Water absorption sequence tests
Low temperature resistance test
Brake fluid compatibility test
Ozone resistance test
Dynamic ozone test
High temperature impulse test
End fitting corrosion test
Constriction test
1) Brake lining
Brake testing
Cold performance equivalence test
Speed sensitivity test
Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient
2) Brake drum and brake disc
Geometric requirements
Performance tests according to Regulations No. 13/13-H
Comparison test with dynamic frictional properties of the original part
high load and thermal fatigue test
1) Brake Linings
Shear test
Dilation and growth
Asbestos detection
Hot compressibility
Compressibility ambient temperature
Hot compressibility
2) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
1) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information
1) Brake lining
Brake testing
Cold performance equivalence test
Speed sensitivity test
Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient
2) Motor Vehicle Brake Fluids
Equilibrium reflux boiling point
Wet ERBP
Kinematic viscosities
pH value
Fluid stability
Corrosion
Fluidity and appearance at low temperatures
Water tolerance
Compatibility
Resistance to oxidation
Effect on SBR cups
Stroking properties
Container information

Marks
ATIC | A Testing Inspection Certification Company
www.atic-cn.com
Get a Quotation Now

Log in to ATICTM Digital Customer Platform to request quotations, browse 16000+ regulations and
SoPs cover more than 54 countries, submit information documents and manage your certification projects.

Global Homologation Solution

ATIC CCC Certification Service

China Compulsory Certification (also known as CCC certification) is the compulsory product certification in China. According to the requirements of CNCA (Certification and Accreditation Administration of the People’s Republic of China), all products listed in the compulsory product certification catalog which does not obtain a certificate or apply certification marks in accordance with regulations, shall not be imported, shipped from the factory, or enter into Chinese market.

The State Administration for Market Regulation issued Announcement No. 19 of 2020 to convert the brake lining from production license to mandatory certification scheme (CCC certification). Brake linings for automobiles will be subject to mandatory CCC certification from June 1, 2020. CNCA-C11-20: 2020 CNCA implementation rules for compulsory product certification of automotive brake linings has been released. The basic certification procedure includes: initial factory audit, sample testing, surveillance. Surveillance activity includes three methods: follow-up inspection after certification, sampling or inspection at the production site, and market sampling inspection or inspection.

Standards:
GB 5763

Test Items:
Asbestos detection, Harmful elements detection, Friction performance test, Shear strength test

Procedure:
Application documents preparation, factory audit, sample tests, certificate issuance, surveillance

Please click here for more certification:
ATIC CCC Certification Service

The CQC mark is applied to indicate that the products meet the relevant quality, safety, performance, electromagnetic compatibility and other certification requirements. The certification scope covers more than 500 products including mechanical equipment, electrical equipment, electrical appliances, electronic products, textiles, and building materials. The CQC mark certification focuses on safety, electromagnetic compatibility, performance, hazardous substance limits and other indicators that directly reflect product quality and affect the personal and property safety of consumers. It is designed to protect consumer interests, promote product quality, and enhance the international competitiveness of domestic enterprises.

Motor vehicle brake hoses were once in the scope of CCC compulsory certification, and were certified according to the CNCA-C11-06 Motor Vehicle Brake Hose Compulsory Product Certification Implementation Rules. According to the Announcement No. 11 of 2018 issued by the State Administration for Market Regulation of China in June 2018, the brake hoses for motor vehicles have been removed from the scope of compulsory certification products, and compulsory certification is no longer conducted.

Although motor vehicle brake hoses no longer require CCC compulsory certification, manufacturers can consider CQC mark certification (voluntary certification) as appropriate. China Quality Certification Center (CQC) has included motor vehicle brake hoses in the scope of CQC mark certification, and according to CQC16-491284-2018 motor vehicle brake hose implementation rules to certify it. In addition to brake hoses, M-type and N-type vehicle brake assemblies and automotive dual-chamber hydraulic brake master cylinder assemblies can also undergo voluntary CQC mark certification to enhance brand value.

Standards:
GB 16897

Test Items:
Expansion testBurst strength test, Anti-jitter test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test

Procedure:
Application documents preparation, factory audit, sample tests, certificate issuance, surveillance

Please click here for more certification:
ATIC EU Homologation

Focusing on road safety, environmental protection and public health, people may mention three sets of famous regulations when they talk about European Type Approval System: German StVZO, EU Regulations and UN Regulations. StVZO standards apply to Germany, EU Regulations apply to EU/EEA/EFTA member states, while UN Regulations may accepted by EU and more than 50 UNECE member states.

Regulation:
ECE R90, ECE R13, ECE R13H, ECE R78

Brake Lining/Shoe Test Items:
Brake testing, Cold performance equivalence test, Speed sensitivity test, Mechanical characteristics, Shear strength, Compressibility, Friction coefficient

Brake Disc/Drum Test Items:
Geometric requirements, Performance tests according to Regulations No. 13/13-H, Comparison tests with dynamic frictional properties of the original part, High load and thermal fatigue tests

Procedure:
Prepare information document, initial assessment, witness test, approval, conformity of production

Please Click here for more EU Certification:
dcb5232a203a2a1fb91eeebb45aebf69

The United States Department of Transportation, abbreviated DOT, is headquartered in Washington. As the functional department of the US government, the US Department of Transportation develops and improves transportation and transportation-related regulations to meet environmental and national defense needs. The Department of Transportation is also a basic department of the federal government, responsible for formulation and management to protect and improve the safety, appropriateness and effectiveness of transportation system. According to the regulations of the US Department of Transportation, where vehicles and critical components are exported to the US market, they must pass DOT certification and mark the corresponding DOT mark on the product. The product has passed the DOT certification and is marked with the corresponding mark, indicating that the product meets the requirements of the Federal Motor Vehicle Safety Standard (FMVSS) and has passed the corresponding test or manufacturer's statement.

Standards:
FMVSS 106, FMVSS 116, SAE J 1288-2005, SAE J 1401-2003, SAE J 1402-2006, SAE J 1403-2005, SAE J 1406-2007, SAE J 1873-2003, SAE J 75-2006, SAE J 291-1980, SAE J 1703-2008, SAE J 1704-2008, SAE J 1705-2007, SAE J 1706-1995, SAE J 1707-2002

Motor Vehicle Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Brake Hose (Hydraulic/Pneumatic/Vacuum) Testing Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test, etc.,

Procedure:
Testing, DOT marking, registration to NHTSA

Please click here for more North America certifications:
北美ameca

The North American Parts Compliance Program (ECP) promoted by AMECA (The Automotive Manufacturers Equipment Compliance Agency, Inc.) is a centralized, voluntary, one-stop process. It is a procedure for informing the government, industry and the general public that motor vehicle safety components have been tested in AMECA authorized laboratories and that they meet relevant standards. Products with an AMECA certificate will be more easily procured by North American buyers and users. AMECA provides product testing related services by authorizing third-party laboratories. Only test reports issued by AEMCA authorized laboratories will be approved by AMECA.

Standard:
FMVSS 106, FMVSS 116, VESC V-3 , SAE J 1288-2005, SAE J 1401-2003, SAE J 1402-2006, SAE J 1403-2005, SAE J 1406-2007, SAE J 1873-2003, SAE J 75-2006, SAE J 291-1980, SAE J 1703-2008, SAE J 1704-2008, SAE J 1705-2007, SAE J 1706-1995, SAE J 1707-2002

Brake Lining Testing Items:
Baseline run, First run, Wear run , Second run, Baseline rerun

Motor Vehicle Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Brake Hose (Hydraulic/Pneumatic/Vacuum) Testing Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test, etc.

Procedure:
Application, testing, certificate issuance

Please click here for more North America certifications:
ATIC Japan Vehicle Type Approval Service

The Japanese Industrial Standards Committee (JISC), Japan's national standardization body, plays a central role in developing standards in Japan covering a wide range of products and technologies from robots to pictograms. JISC is also responsible for Japan's growing contribution to setting international standards through its work with the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC).

Japanese Industrial Standards (JIS) covers industrial and mineral products, data, services and management systems under the Industrial Standardization Act.

Businesses that receive certificates of conformity from accredited certification bodies are eligible to display the JIS Mark on their products, electromagnetic record provision documents or service provision documents, etc. All certification bodies accredited for the JIS marking system must be compliant with ISO/IEC 17065. The certification process consists of two elements: evaluation of the conformity of products, electromagnetic records, or services with the relevant JIS, and the evaluation of the quality management system. As of March 2019, there are 24 JIS-accredited certification bodies, including three outside of Japan, which have issued about 8,700 certifications for JIS Marks.

Standards:
JISD4413, JISD4414-1, JISD4414-2, JISD4415, JISD4416, JISD4417, JISD4418, JISD4419, JISD4420, JISD4421, JISD4422, JISK2233, JISD2601

Brake Lining Test Items:
Compressive strain test, Anti-rust test, Shear strength test, Thermal expansion test, Hardness test, Shear test

Brake Fluids Test Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Hydraulic Brake Hose Test Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test

Please click here for more Japan certifications:
ADR certification

The Road Vehicle Standards Act 2018 (RVSA) and associated Road Vehicle Standards Acts relating to consequential and transitional provisions and charges passed Parliament in late 2018. The Road Vehicle Standards Rules 2019, which cover the operational aspects of the RVSA, were made in February 2019. The RVSA will replace the existing Motor Vehicle Standards Act 1989 (MVSA) and deliver an updated and modernized system to regulate the first provision of road vehicles to the Australian market.

In Australia, the entire process from application to obtaining an Identification Plate is called Certification. The entire certification process is managed by Australian Department of Infrastructure, Transport, Regional Development and Communications and operated through Vehicle Safety Standards Branch (VSS).

The scope of vehicle certification includes: Motor Vehicles, Trailers, Tractors, Bicycles, Used Imported Cars, Special Vehicles, etc. Component certification includes: Automotive Lamps, Rearview Mirrors, Seat Belts, Brake Hoses, Glass, Tires, Retro-reflectors, Filament Bulbs, Couplings, Seats, etc.


Standard:
ADR7, ADR42

Brake Hose (Hydraulic/Pneumatic/Vacuum) Test Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test, High temperature resistance test, Oil resistance test, Length change test, Flex strength and air pressure test, Corrosion resistance and burst strength test, Water Absorption and tensile strength test, Zinc chloride resistance test, Vacuum test, Bend test, Swell and adhesion test, Deformation test

Procedure:
Prepare information document, sample testing, submit registration

ATIC Korea Vehicle Type Approval

Korean product safety KC certification is a compulsory certification implemented by the Korean state. It is supervised by the Ministry of Trade, Industry and Energy of Korea which formulates related laws, enforcement decrees and rules on product safety. According to the Korean Electrical Appliances and Consumer Goods Safety Management Act, and the Korean Special Children's Products Safety Management Act, the certification scope includes three categories: electrical appliances, household products and children's products. Among them, there are 442 of electrical appliances that require compulsory certification, 66 of household products, and 36 of children's products. For these nearly 600 kinds of products within compulsory safety certification scope, the Ministry of Trade, Industry and Energy has stipulated different procedures of certification according to their safety levels, includes: safety certification, safety inspection and supplier’s declaration of conformity. Products within the compulsory certification scope must conduct KC certification and bear the KC mark on their products before entering the South Korean market.

Standards:
KMVSS Article 112-2, KMVSS Article 112 -10, National Technical Standards Notice No. 2017-032

Brake Lining Testing Items:
Compressibility test, Shear strength test, Hardness Testing

Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Brake Hose (Hydraulic/Pneumatic/Vacuum) Testing Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test, etc.

Procedure:
Prepare documents, testing, submit registration, approval

Please click here for more Korea certifications:
ATIC Philippine Vehicle Type Approval

Philippines began implementing the compulsory product certification system on August 2, 2006. The authority is the Department of Trade and Industry (DTI). The regional office of DTI is responsible for certification-related testing and auditing activities. The Bureau of Product Standards (BPS) is subordinate unit of Department of Trade and Industry Philippines (DTI). It is responsible for the development, implementation and coordination of all standardization and the development of the BPS national standards in Philippines. Bureau of Product Standards (BPS) includes Standards and Regulations Department, Standard Information Service Department, Product Certification Department, Quality Management System Certification Department, and Conformity Assessment Body Accreditation Department.

Motor vehicle components requiring mandatory certification include tires, brake fluids, seat belts, safety glazing, helmets, LPG cylinders, etc.

Standard:
PNS 239/MVSS 116:1988

Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Procedure:
Submit application, initial factory audit (if needed), testing, approval, surveillance

Please click here for more Philippines certification:
ATIC Vietnam Vehicle Type Approval Serivce

The Vietnamese motor vehicle type approval authority is Ministry of Transport of Vietnam (MT) and its subdivision Vietnam Register (VR). For both imported and local assembled motor vehicles there are type approval procedures need to follow.

Since the year of 2018, Vietnam Register has mandated certification for aftermarket auto parts includes helmets, glazing, wheels, rearview mirrors, tires, headlamps, fuel tanks, batteries, interior materials, pressure vessels, power batteries, etc.

Standard:
22TCN 296-02, TCVN 11496-2016, TCVN 11497-2016, TCVN 11498-2016, TCVN 11499-2016, TCVN 11500-2016, TCVN 11501-2016, TCVN 11502-2016, TCVN 11503-2016, TCVN 11496-2016, TCVN 6822-2001, TCVN 6823-2001, TCVN 7237-2003, TCVN 7236-2003, TCVN 7235-2003

Motorcycle Brake Hose Testing Items:
Tolerance for length, Requirement of fitting, Installation of cap and cove, Threaded joints requirement, Length of patchwork and lead holding material, Surface defects, Conductor surface requirements, Installation of protective covers, Slip resistance, Control performance, Durability

Procedure:
Submit application, factory audit, sample delivery, testing, certificate issuance, conformity of production

Please click here for more Vietnam certification:

Vietnam VR Certificate Example

Vietnam Vehicle and Component VR Certification

821e52f4085d629cdf134c79c788e01b

CMVR is the abbreviation of Central Motor Vehicles Rules. Its standard committee is called CMVR-TSC (CMVR-Technical Standing Committee) and belongs to the Indian Ship, Road Traffic and Highway Administration. Since 1991, the CMVR regulations stipulate that motor vehicles and their systems and components must be approved according to the CMVR regulations before entering the Indian market. The tests includes Safety, Emissions and the type approval process includes Factory Audit, Type Testing and Conformity of Production (CoP).

Standards:
AIS-061, IS 7079-2008

Brake Lining Test Items:
Brake testing, Cold performance equivalence test, Speed sensitivity test, Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient

Hydraulic Brake Hose Test Items:
Expansion test, Burst strength test, Whip resistance test, Tensile strength test, Water absorption sequence tests, Low temperature resistance test, Brake fluid compatibility test, Ozone resistance test, Dynamic ozone test, High temperature impulse test, End fitting corrosion test, Constriction test

Procedure:
Application, factory audit, sample test, approval, surveillance audit

Please click here for more Vietnam certification:

India motor vehicle and component type approval

India BOV CMVR type approval

ATIC UAE ESMA Certification

ESMA has established Technical Committees in the fields of food products, construction and building materials products, electrical and electronic products, chemical and plastic products, mechanical products, petroleum products and lubricants, and metrology and information technology.

The Cabinet Resolution No (12) of 2018 Automotive Spare Parts was published in 2018 by Prime Minister, United Arab Emirates which stipulates that 14 categories of auto parts are prohibited to import or place the product in the market subject to the provisions of this decision unless it is registered in accordance with the UAE conformity assessment scheme (ECAS) and has obtained a certificate of conformity in accordance with the provisions of this resolution. Including: Brake Systems, Brake Pads, Engine Radiators, Safety Belts, Rear View Mirrors, Batteries, Oil Filters for Internal Combustion Engines, Air Filters, Laminated Safety Glass, Rims, Door Locks and Door Hinges, Retro-reflective Markings and Signaling Devices, Alarm Systems for Buses and Commercial Vehicles, Relays and Flashers.

Standards:
UAE.S/GSO ECE 90, UAE.S GSO ECE 13-1, UAE.S GSO ECE 13-2, UAE.S GSO ECE 13-3, UAE.S GSO ECE 13-4, UAE.S GSO ECE 13-5, UAE.S GSO ECE 13-6, UAE.S GSO ECE 13H

Brake Lining/Shoe Testing Items:
Brake testing, Cold performance equivalence test, Speed sensitivity test, Mechanical characteristics Test-Shear strength, Compressibility, friction coefficient

Brake Disc/Drum Testing Items:
Geometric requirements, Performance tests according to Regulations No. 13/13-H, Comparison test with dynamic frictional properties of the original part, high load and thermal fatigue test

Procedure:
Submit registration, sample testing, certificate issuance, registration approval
Vehicle EAC Certification

The Eurasian Economic Union (EAEU), also known as the Eurasian Union (EEU), was formerly the Customs Union (abbreviated as CU) of Russia, Belarus and Kazakhstan. Armenia and Kyrgyzstan subsequently joined the union, and the Eurasian Economic Union was formally established in 2015.

Eurasian Conformity (EAC) is a product certification system formulated and implemented by the Eurasian Union. At present, the Eurasian Union is expected to issue 66 product technical regulations, and 48 regulations have been enforced. The product scope covers a wide range of food, electrical appliances, children products, transportation, chemicals, light industrial products and other fields. All products listed in the unified list of EAC certification, without obtaining a certificate or applying the certification mark in accordance with regulations, shall not be imported, sold, or used in business service places.

Standard:
TR TS 030/2012

Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information

Procedure:
Submit application, factory audit (if needed), sample testing (if needed), certificate issuance, maintenance
零部件

INMETRO (National Institute of Metrology, Standardization and Industrial Quality) is a government department directly under the Ministry of Development, Industry and Foreign Trade of Brazil. With the enactment of new ordinances and implementation laws, more and more products are included into INMETRO mandatory certification scheme.

Our INMETRO certification service scope covers LED Light Sources, Road Lamps, Automotive Parts, Motorcycle Parts, Bicycle Parts, Dangerous Goods Transportation, Child Seats, Photovoltaic Products, Pressure Vessels, Household Appliances, Children's Toys and Supplies, Building Structure, Personal Protective Equipments, Explosive Atmosphere, Medical Equipments etc., a total of more than 700 products in 155 categories.

Standards:
Ordinance no. 55, Ordinance no. 78

Brake Lining Testing Items:
Shear test, Dilation and growth, Asbestos detection, Hot compressibility, Compressibility ambient temperature, Hot compressibility

Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties


Procedures:
Application, factory audit, testing, certificate issuance, maintenance

Please click here for more Brazilian certification:
Argentina Component Type Approval

Argentine Ministry of Industry’s Regulation No. 91 of 2001 and Regulation No. 66 of 2008 established the mandatory certification system (Certificate of Homologation of Auto Safety Part - Certificado de Homologación de Autoparte de Seguridad - C.H.A.S.) for Argentine automotive aftermarket parts and safety units, which is applicable for both imported or local produced products. Related aftermarket parts shall be certified and registered with the Argentine Ministry of Industry before being allowed to be sold in the Argentine market.

Standards:
IRAM AITA 6-C2, IRAM AITA, 6H1, 6H2, 6H3, 6H4, 6H5, 6H10

Brake lining Testing Items:
Brake testing, Cold performance equivalence test, Speed sensitivity test, Mechanical characteristics (Shear strength, Compressibility, Friction coefficient)

Brake Fluids Testing Items:
Equilibrium reflux boiling point, Wet ERBP, Kinematic viscosities, pH value, Fluid stability, Corrosion, Fluidity and appearance at low temperatures, Water tolerance, Compatibility, Resistance to oxidation, Effect on SBR cups, Stroking properties, Container information


Procedure:
Submit application, factory audit (if needed), sample test (if needed), approval, surveillance

Please click here for more Argentina certification:

Multinational Homologation Solutions
ATIC provides more than 28 categories' system, separate technical unit, component multinational compliance and homologation solutions

CNG/LPG Components
Many countries established regulations and homologation procedures for clean energy applications. ATIC team has accumulated many years homologation experience in this area. We are now providing comprehensive services including multinational regulations identification, regulation comparison, training, Q&A, testing and homologation.

Europe, the United States, Japan, Korea, China and India have a comprehensive electric vehicle homologation system. Emerging markets such as the Middle East, Indonesia, and Thailand are gradually developing electric vehicle standards. Our service includes multinational regulations identification, comparison, training and Q&A.

CNG/LPG Components
Many countries established regulations and homologation procedures for clean energy applications. ATIC team has accumulated many years homologation experience in this area. We are now providing comprehensive services including multinational regulations identification, regulation comparison, training, Q&A, testing and homologation.

Brake system components such as brake lining, brake pads and shoes, brake discs are critical safety components. Most countries established compulsory certification scheme for both original and replacement parts. Our market access solution including regulation consulting, training, testing and certification covering all the relevant countries/regions world wide.

Tires are required for mandatory certification in many countries. Besides safety testing, many countries are introducing labelling requirements with regard to the display of information on the fuel efficiency, wet grip and external rolling noise of tires. ATIC provides multinational consulting and homologation services for tires, especially for emerging markets.

In-vehicle communication system is more and more important in internet of vehicle systems. Both automotive and telecom regulations need to be considered. Relying on our professional team and regulation database ATIC provides in-vehicle communication system homologation, training and consulting services covering more than 17 countries.
